Характеристики
| Product Type (General) | Motherboard - micro ATX |
| Chipset Type (General) | Intel B860 |
| Processor Socket (General) | LGA1851 Socket |
| Max Processors Qty (General) | 1 |
| Compatible Processors (General) | (supports Intel Core Ultra processors (Series 2)) |
| Max Size (Supported RAM) | 128 GB |
| Technology (Supported RAM) | DDR5 |
| Bus Clock (Supported RAM) | 9066 MHz (O.C.), 6400 MHz, 6800 MHz (O.C.) |
| Supported RAM Integrity Check (Supported RAM) | Non-ECC |
| Registered or Buffered (Supported RAM) | Unbuffered, clocked unbuffered |
| Features (Supported RAM) | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) 3.0, AMD EXPO technology |
| Type (Audio) | HD Audio (8-channel) |
| Audio Codec (Audio) | Realtek ALC897 |
| Compliant Standards (Audio) | High Definition Audio |
| Network Controller (LAN) | Dragon RTL8125BG |
| Network Interfaces (LAN) | 2.5 Gigabit Ethernet |
| Expansion Slots (Expansion / Connectivity) | 1 x CPU 2 x DIMM 288-pin 1 x PCIe 4.0 x16 1 x PCIe 4.0 x1 1 x PCIe 4.0 x4 1 x M.2 socket (2230 M.2 Key E slot) 1 x M.2 socket (2260/2280 M.2 Key M slot) 1 x M.2 socket (2230/2242/2260/2280 M.2 Key M slot) |
| Storage Interfaces (Expansion / Connectivity) | SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 5.0 -connectors: 1 x Blazing M.2 PCIe 4.0 -connectors: 1 x Hyper M.2 |
| Interfaces (Expansion / Connectivity) | 1 x USB-C 3.2 Gen2x2 3 x USB 3.2 Gen 1 2 x USB 2.0 1 x LAN (2.5Gigabit Ethernet) 1 x HDMI 1 x DisplayPort 1 x audio line-in - mini-jack 1 x microphone - mini-jack 1 x audio line-out - mini-jack |
| Internal Interfaces (Expansion / Connectivity) | 4 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x USB-C 3.2 Gen 1 - header 1 x SPI - header 1 x audio - header |
| Power Connectors (Expansion / Connectivity) | 24-pin main power connector, 8-pin ATX12V connector, 4-pin ATX12V connector |
| BIOS Type (Features) | AMI |
| BIOS Features (Features) | UEFI BIOS |
| Hardware Features (Features) | BIOS FlashBack button, ASRock EZ Mode, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Instant Flash, ASRock Auto Driver Installer, Intel Hybrid Technology, Intel Turbo Boost Max Technology 3.0, Intel Thermal Velocity Boost (TVB), Intel Adaptive Boost Technology (ABT), ASRock POST Status Checker (PSC), 7+1+1+1+1 Power Phase Design, 6 Layer PCB, aluminium heatsink design, chipset heatsink, ASRock Polychrome RGB, DIY Friendly Design, CUDIMM support |
| Included Accessories (Miscellaneous) | 2 x M.2 screws, standoff for M.2 socket, IO shield |
| Cables Included (Miscellaneous) | 2 x Serial ATA cable |
| Software Included (Miscellaneous) | ASRock A-Tuning, ASRock Dragon 2.5G LAN Software, ASRock Polychrome SYNC |
| Compliant Standards (Miscellaneous) | FCC, ErP Ready, EuP Ready, HDCP 2.3, DisplayPort 1.4 |
| Width (Miscellaneous) | 24.4 cm |
| Depth (Miscellaneous) | 21.8 cm |
