| Серия |
Phantom Gaming |
| Процесор |
Intel 1700 |
| Чипсет |
Intel Z790 |
| BIOS |
128Mb AMI UEFI Legal BIOS with GUI support |
| Памет, слотове |
4 x DDR4 DIMM Slots, Max. capacity of system memory: 128GB |
| Аудио |
7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio |
| Мрежа |
2.5 Gigabit LAN 10/100/1000/2500 Mb/s, Dragon RTL8125BG, Supports Phantom Gaming LAN Software |
| Конектори |
SPI TPM Header, eDP Signal Connector, Power LED and Speaker Header, 24 pin ATX Power Connector, 2 x 8 pin 12V Power Connectors, Front Panel Audio Connector, Thunderbolt AIC Connector (5-pin), USB 2.0 Header, 2 x USB 3.2 Gen1 Headers, Front Panel Type C |
| Слотове |
CPU: PCIe 5.0 x16 Slot (PCIE1); Chipset: PCIe 4.0 x16 Slot (PCIE4), 3 x PCIe 3.0 x1 Slots |
| M.2 слот |
M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT) |
| Интерфейс |
2 x Antenna Mounting Points, PS/2 Mouse/Keyboard Port, HDMI Port, USB 3.2 Gen2 Type-A Port, USB 3.2 Gen2x2 Type-C Port, 5 x USB 3.2 Gen1 Ports, USB 2.0 Port, RJ-45 LAN Port, HD Audio Jacks: Line in / Front Speaker / Microphone |
| Софтуер |
ASRock Motherboard Utility (Phantom Gaming Tuning), ASRock Phantom Gaming LAN Software, ASRock Polychrome SYNC |
| Операционна система |
Microsoft Windows 10 64-bit / 11 64-bit |
| Форм-фактор |
ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
| Специални функции |
Superb Productivity, Rock-Solid Durability, Ultrafast Connectivity, EZ Troubleshooter |
