48-портов Gigabit Stackable L3 управляем

Запитай

Сравни

48-портов Gigabit Stackable L3 управляем комутатор с 6 10G слота TP-Link Omada SG6654XHP

Наличност: на склад

6 921.78лв. с ДДС

Продуктов код: SG6654XHP_VZ

Добави

Характеристики

L3 Switching Features	VRRP: Version v2/v3, Max 64 groups
L3 Switching Features	Max 1,024, IPv6: Max 512
Интерфейс	6× 10G SFP+ Slots
Наличност	Ограничена - под 10 бр.
VLAN	Voice VLAN
Quality of Service	Voice VLAN
Захранване	Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz)
Интерфейс	1× USB Type-C Console Port
Интерфейс	48 10/100/1000Mbps RJ45 Ports
Ethernet портове	6× 10G SFP+ Slots
ХИТ	N
Експлоатационни качества	Switching Capacity 216 Gbps per Unit
Експлоатационни качества	Packet Forwarding Rate 160.7 Mpps
L3 Switching Features	Static Routing
Работна температура	-5 °C to 50 °C (23 °F to 122 °F) @ 300 meters
L2 Switching Features	Static Link Aggregation
VLAN	Max. 4K VLAN Groups
L3 Switching Features	Max 1,000 Manual Binding Entries
L2 Switching Features	Multicast Filtering
Интерфейс	1× RJ45 Management Port
L2 Switching Features	IGMP Snooping
Quality of Service	Class of Service
L2 Switching Features	RSPAN
L3 Switching Features	Static ARP: 512 static entries
Софтуерни функции	VLAN
Критерии за валидност на гаранцията	Гаранционна карта/Сериен номер
VLAN	VLAN VPN (QinQ): Max 256 entries
Размери дълбочина	380 mm
L2 Switching Features	L2 Multicast Table
L3 Switching Features	IPv4: Max 256, IPv6: Max 256
Филтър Swich	48 порта
Размери ширина	440 mm
Ethernet портове	1× RJ45 Management Port
Системни изисквания	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
L3 Switching Features	RIP: Version v1/v2, Max 8,190
L2 Switching Features	Multicast
L2 Switching Features	Port-based and VLAN-based Loopback Detection
Размери височина	44 mm
L2 Switching Features	802.3x Flow Control
VLAN	Management VLAN
Работна температура	-5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters
Работна температура	-5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters
Гаранция	60 месеца
Quality of Service	User-Defined OUI
L3 Switching Features	IP Interfaces:
Quality of Service	Bandwidth Control
Софтуерни функции	Quality of Service
L3 Switching Features	Relayed VLAN
Експлоатационни качества	Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports)
L2 Switching Features	Fast Leave
L2 Switching Features	Static Multicast IP
L2 Switching Features	MAC Address Table
Brand	TP-LINK
L3 Switching Features	Host Route Table: Max 6,100 entries
Софтуерни функции	L2 and L2+ Features
Софтуерни функции	L3 Features
L2 Switching Features	Spanning Tree Protocol
L3 Switching Features	Relayed Interface
L3 Switching Features	ECMP: 256 entries, max 32 ECMP Nexthops per Destination
L3 Switching Features	Proxy ARP
L3 Switching Features	Dynamic ARP: 7,680 dynamic entries
L3 Switching Features	OSPF: Version v2/v3; v2: Max 8,190, v3: Max 4,097
L3 Switching Features	DHCP Server:
L2 Switching Features	PIM-DM, PIM-SM (IPv4)
Вид на монтаж	Rackmount
Интерфейс	2× USB 2.0 Ports
Интерфейс	1× RJ45 Console Port
L3 Switching Features	Max 64 IP Pools
L2 Switching Features	Supports 2,048 IGMP groups
Софтуерни функции	Security
Софтуерни функции	Advanced Features
Филтър Swich - PoE, SFP	SFP+ slots
L2 Switching Features	MLD Snooping
VLAN	VLAN VPN (QinQ)
Експлоатационни качества	MAC Address Table 32 K
Експлоатационни качества	Stacking Number: 8
Ethernet портове	48× 10/100/1000 Mbps RJ45 Ports
Ethernet портове	1× RJ45 Console Port
L2 Switching Features	Multicast VLAN Registration (MVR)
Quality of Service	Smoother Performance
Работна влажност	10%~90% без кондензация
VLAN	MAC VLAN Entries: 200
L2 Switching Features	ERPS
VLAN	Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries
VLAN	GVRP
Влажност на съхранение	10%~90% без кондензация
L3 Switching Features	DHCP Server/Relay
Експлоатационни качества	Jumbo Frame 9 KB
Quality of Service	Action for Flows
VLAN	Private VLAN
VLAN	802.1q Tagged VLAN
VLAN	Multicast VLAN
