Характеристики
| Product Type (General) | Motherboard - micro ATX |
| Chipset Type (General) | Intel Z890 |
| Processor Socket (General) | LGA1851 Socket |
| Max Processors Qty (General) | 1 |
| Compatible Processors (General) | (supports Intel Core Ultra processors (Series 2)) |
| Max Size (Supported RAM) | 192 GB |
| Technology (Supported RAM) | DDR5 |
| Bus Clock (Supported RAM) | 4333 MHz (O.C.) |
| Supported RAM Integrity Check (Supported RAM) | Non-ECC |
| Registered or Buffered (Supported RAM) | Unbuffered |
| Features (Supported RAM) | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Type (Audio) | HD Audio (8-channel) |
| Compliant Standards (Audio) | High Definition Audio |
| Network Interfaces (LAN) | 2.5 Gigabit Ethernet |
| Expansion Slots (Expansion / Connectivity) | 1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 2 x PCIe 4.0 x16 (x4 mode) 1 x PCIe 4.0 x16 (x1 mode) 1 x M.2 socket (2280 M.2 slot) 1 x M.2 socket (2242/2260/2280 M.2 Key M slot) 2 x M.2 socket (2280/22110 M.2 Key M slot) |
| Storage Interfaces (Expansion / Connectivity) | SATA-600 -connectors: 6 x 7pin Serial ATA PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 |
| Interfaces (Expansion / Connectivity) | 1 x DisplayPort 1 x HDMI 1 x USB-C 3.2 Gen2x2 1 x LAN (2.5Gigabit Ethernet) 1 x USB 3.2 Gen 2 2 x USB 3.2 Gen 1 4 x USB 2.0 2 x aerial 1 x microphone - mini-jack 1 x audio line-out - mini-jack 1 x audio line-in - mini-jack |
| Internal Interfaces (Expansion / Connectivity) | 1 x USB-C 3.2 Gen 2 - header 4 x USB 3.2 Gen 1 - header 4 x USB 2.0 - header 1 x serial - header 1 x audio - header 1 x SPI - header 1 x Thunderbolt 4 - header 1 x SPDIF out - header |
| Power Connectors (Expansion / Connectivity) | 24-pin main power connector, 2 x 8-pin ATX12V connectors |
| BIOS Type (Features) | AMI |
| BIOS Features (Features) | UEFI BIOS, ASUS EZ Flash, ASUS UEFI BIOS EZ Mode |
| Sleep / Wake Up (Features) | Wake on LAN (WOL), wake on PME |
| Hardware Features (Features) | Intel Turbo Boost Technology 2.0, Intel Turbo Boost Max Technology 3.0, ASUS Enhanced Memory Profile (AEMP) III, CUDIMM support, LANGuard, ASUS 5X Protection III, ASUS Aura Sync, ASUS DIGI+ VRM, ASUS EZ DIY, ASUS Overvoltage Protection, ASUS ProCool, ASUS Q-Design, ASUS SafeSlot, ASUS Stainless Steel Back I/O, BIOS FlashBack button, BIOS FlashBack LED, pre-mounted I/O shield, Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED Core, Q-Slot, VRM heatsink design, CrashFree BIOS 3, Preboot eXecution Environment (PXE), 14+1+2+1 Phase Power Design, chipset heatsink, AI Networking II, AI Cooling II, NPU Boost, 6 Layer PCB, PCIe Slot Q-Release |
| Included Accessories (Miscellaneous) | 2 x M.2 screw package, 1 x M.2 rubber package |
| Cables Included (Miscellaneous) | 2 x SATA Express cable |
| Software Included (Miscellaneous) | Armoury Crate, ASUS Fan Xpert 4, ASUS DriverHub, ASUS CPU-Z, Norton 360 Deluxe (60 days trial), TurboV Core, WinRAR (40 days trial) |
| Compliant Standards (Miscellaneous) | DisplayPort 1.4 |
| Width (Miscellaneous) | 30.5 cm |
| Depth (Miscellaneous) | 24.4 cm |
