Характеристики
| Product Type (General) | Motherboard - ATX |
| Chipset Type (General) | Intel B760 |
| Processor Socket (General) | LGA1700 Socket |
| Max Processors Qty (General) | 1 |
| Compatible Processors (General) | (supports 12th Generation Intel Core / Pentium Gold / Celeron) |
| Max Size (Supported RAM) | 128 GB |
| Technology (Supported RAM) | DDR4 |
| Supported RAM Integrity Check (Supported RAM) | Non-ECC |
| Registered or Buffered (Supported RAM) | Unbuffered |
| Features (Supported RAM) | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Type (Audio) | HD Audio (8-channel) |
| Compliant Standards (Audio) | High Definition Audio, Digital Theater Systems (DTS) |
| Network Interfaces (LAN) | 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.2 |
| Expansion Slots (Expansion / Connectivity) | 1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x PCIe 3.0 x16 (x4 mode) 2 x PCIe 3.0 x1 2 x M.2 socket (2242/2260/2280 M.2 Key M slot) 1 x M.2 socket (2242/2260/2280/22110 M.2 Key M slot) |
| Storage Interfaces (Expansion / Connectivity) | SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 3 x M.2 |
| RAID Features (Expansion / Connectivity) | Intel Rapid Storage Technology |
| Interfaces (Expansion / Connectivity) | 1 x HDMI 1 x DisplayPort 2 x aerial 1 x USB 3.2 Gen 2 1 x USB 2.0 1 x LAN (2.5Gigabit Ethernet) 1 x USB-C 3.2 Gen2x2 3 x USB 3.2 Gen 1 1 x SPDIF out 1 x audio line-in - mini-jack 1 x microphone - mini-jack 1 x audio line-out (center/subwoofer) - mini-jack 1 x audio line-out (front surround) - mini-jack 1 x audio line-out (back surround) - mini-jack |
| Internal Interfaces (Expansion / Connectivity) | 4 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x USB-C 3.2 Gen 1 - header 1 x audio - header 1 x serial - header 1 x Thunderbolt - header |
| Power Connectors (Expansion / Connectivity) | 24-pin main power connector, 8-pin ATX12V connector, 4-pin ATX12V connector |
| BIOS Type (Features) | AMI |
| BIOS Features (Features) | ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode, UEFI BIOS |
| Sleep / Wake Up (Features) | Wake on LAN (WOL), wake on PME |
| Hardware Features (Features) | ASUS OptiMem II, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, Water Pump Header, ASUS DIGI+ VRM, Dr.MOS MOSFET, TUF ESD Guards, TUF LANGuard, overvoltage protection, ASUS SafeSlot Core+, ASUS Stainless Steel Back I/O, ASUS Q-Design, Q-DIMM, Q-LED, M.2 Q-Latch, Q-Slot, M.2 heatsink, VRM heatsink design, ASUS EZ DIY, ASUS ProCool, ASUS SafeDIMM, pre-mounted I/O shield, ASUS Aura Sync, ASUS TUF Protection, CrashFree BIOS 3, Preboot eXecution Environment (PXE), Windows 11 compatible, 12+1 Phase Power Design, 6 Layer PCB, ProCool Power Connector |
| Included Accessories (Miscellaneous) | ASUS Wi-Fi moving aerial, TUF GAMING sticker, 2 x M.2 rubber package, M.2 screw package, TUF certification card |
| Cables Included (Miscellaneous) | 2 x Serial ATA cable |
| Software Included (Miscellaneous) | ASUS AURA Creator, ASUS Fan Xpert 4, ASUS AI Suite III, PC Cleaner, ASUS TUF GAMING CPU-Z, MyAsus, Norton 360 for Gamers, WinRAR |
| Compliant Standards (Miscellaneous) | DisplayPort 1.4 |
| Width (Miscellaneous) | 30.5 cm |
| Depth (Miscellaneous) | 24.4 cm |
