Характеристики
| Суич, тип | Fixed Port, Managed |
| Общ брой портове | 12 |
| Основни портове, тип | 10x10GBase-T |
| Power Over Ethernet (PoE) | - |
| Uplink портове | 2x10 Gigabit SFP+ (combo with 2 x 10G copper ports) |
| Свободни (10GB) слотове | - |
| Управление | 1x GE OOB management; Web user interface; Cisco Business Dashboard; CLI; SNMP |
| Stackable | Up to 4 units in a stack. Up to 192 ports managed as a single system with hardware failover |
| Fans | 2 |
| Захранване | Internal (100-240V, 50-60 Hz) |
| Routing | Layer 3 RIP |
| Памет (Flash, RAM) | Flash: 256 MB; CPU memory: 512 MB, Packet buffer: 3 MB |
| Капацитет за маршрутизиране/превключване, Gbps | 240 Gbps |
| Пропускателна способност, Mpps | 178.56 Mpps |
| MAC адреси | 16K |
| VLAN (брой, стандарти) | Support for up to 4094 VLANs simultaneously; Port-based and 802.1Q tag-based VLANs; MAC/protocol-based VLAN; IP subnet-based/Management VLAN; Private VLAN; PVE; Guest/unauthenticated VLAN; Dynamic VLAN assignment via RADIUS server; Voice/Multicast TV VLAN |
| QoS | Priority levels: 8 hardware queues; Scheduling: Strict priority and Weighted Round-Robin (WRR); Class of service: Port based; 802.1p VLAN priority-based; IPv4/v6 IP precedence/Type of Service (ToS)/DSCP-based; DiffServ; ACLs, trusted QoS |
| L2 мрежови стандарти | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x Flow Control, IEEE 802.3 ad LACP, IEEE 802.1D (STP), IEEE 802.1Q/p VLAN, IEEE 802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at, RFC |
| L3 мрежови стандарти | Support for Routing Information Protocol version 2 for dynamic routing |
| IPv6 functionality | IPv6 host mode; IPv6 over Ethernet; Dual IPv6/IPv4 stack; IPv6 neighbor and router discovery (ND); IPv6 stateless address autoconfiguration; MTU discovery; DAD; ICMP v6; DHCPv6 stateful client; ISATAP |
| Сигурност | SSH v1/v2; SSL; IEEE 802.1X; Web-based authentication; IP Source Guard; Dynamic ARP Inspection (DAI); IP/MAC/Port Binding (IPMB); Secure Core Technology (SCT); Secure Sensitive Data (SSD); Port security; RADIUS/TACACS+; RADIUS accounting; Storm control |
| Размери (Ш, Д, В), mm | 440 x 203 x 44 mm |
| Опция за монтаж | Rackmount |
| Други | Cisco standard RJ45 console port; USB Type-A slot on the front panel of the switch for easy file and image management |
