Характеристики
| Device Type (General) | Power supply - internal |
| Specification Compliance (General) | ATX12V 3.0/ EPS12V 2.92 |
| PSU Form Factor (General) | ATX |
| Localisation (General) | Europe |
| Input Voltage (Power Device) | AC 100-240 V |
| Frequency Required (Power Device) | 47 - 63 Hz |
| Power Output Connectors Details (Power Device) | 1 x power 24 pin ATX with detachable 4 pin section 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section 1 x 12VHPWR 2 x 2 x 8 pin PCI Express power with detachable 2 pin section 3 x 8 pin PCI Express power with detachable 2 pin section 16 x 15 pin Serial ATA power 8 x 4 PIN internal power |
| Output Voltage (Power Device) | +3.3, +5, +12 V |
| Power Capacity (Power Device) | 1000 Watt |
| Output Current (Power Device) | +3.3V - 20 A +5V - 20 A +12V - 83.3 A +5VSB - 3 A |
| Efficiency (Power Device) | 90% |
| Modular Cable Management (Power Device) | Yes |
| 80 PLUS Certification (Power Device) | 80 PLUS Gold |
| Included Accessories (Miscellaneous) | Cable ties, mounting screw |
| Cables Included (Miscellaneous) | AC input cable Power 24 pin ATX modular cable 61 cm 16-pin 12VHPWR power cable 65 cm 2 x 2x 8 pin PCI Express power with detachable 2 pin section modular cable 75 cm 3 x 8 pin PCI Express power with detachable 2 pin section modular cable 65 cm 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section modular cable 65 cm 4 x power 15 pin SATA cable 80 cm 2 x 4 pin internal power cable 75 cm |
| MTBF (Miscellaneous) | 100,000 hours |
| Cooling System (Miscellaneous) | 140 mm fan |
| Features (Miscellaneous) | Fully modular, fluid dynamic bearing cooling fan, Zero RPM fan mode, side connections, Modern Standby compatible, LLC resonant converter technology, DC-DC technology, overpower protection, over voltage protection, over current protection, overheat protection, short-circuit protection |
| Compliant Standards (Miscellaneous) | EN 55032:2015+A11:2020, EMC, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019, EN IEC 61000-3-2:2019+A1:2021, EN IEC 62368-1:2020+A11:2020, EN/IEC 63000:2018, LVD, RoHS |
| Service & Support (Manufacturer Warranty) | Limited warranty - 10 years |
| Width (Dimensions & Weight) | 15 cm |
| Depth (Dimensions & Weight) | 18 cm |
| Height (Dimensions & Weight) | 8.6 cm |
| Weight (Dimensions & Weight) | 1.9 kg |
| Shipping Width (Dimensions & Weight (Shipping)) | 21.4 cm |
| Shipping Depth (Dimensions & Weight (Shipping)) | 30.2 cm |
| Shipping Height (Dimensions & Weight (Shipping)) | 12.9 cm |
| Shipping Weight (Dimensions & Weight (Shipping)) | 3.8 kg |
