Характеристики
| Type (General) | Server |
| Product Form Factor (General) | Rack-mountable - 2U |
| Server Scalability (General) | 2-way |
| Front Accessible Bays Qty (General) | 1 |
| Hot-Swap Bays Qty (General) | 4 |
| CPU (Processor / Chipset) | Intel Xeon Silver 4208 |
| Clock Speed (Processor / Chipset) | 2.1 GHz |
| Max Turbo Speed (Processor / Chipset) | 3.2 GHz |
| Number of Cores (Processor / Chipset) | 8-core |
| CPU Qty (Processor / Chipset) | 1 |
| Max CPU Qty (Processor / Chipset) | 2 |
| CPU Upgradability (Processor / Chipset) | Upgradable |
| Chipset Type (Processor / Chipset) | Intel C624 |
| Installed Size (Cache Memory) | 11 MB |
| Cache Per Processor (Cache Memory) | 11 MB |
| Installed Size (RAM) | 16 GB (installed) / 768 GB (max) |
| Technology (RAM) | DDR4 SDRAM - Advanced ECC |
| Effective Memory Speed (RAM) | 2400 MHz |
| Rated Memory Speed (RAM) | 2933 MHz |
| Slots (RAM) | 12 (Total) / 11 (empty) |
| Features (RAM) | Memory Mirroring, slots 7 - 12 are available in two-processor configuration only, Independent Memory Mode, memory rank sparing, memory scrubbing |
| Configuration Features (RAM) | 1 x 16 GB |
| Type (Hard Drive) | No HDD |
| Type (Storage Controller) | 1 x SATA |
| Controller Interface Type (Storage Controller) | SATA 6Gb/s |
| RAID Level (Storage Controller) | RAID 0, RAID 1 |
| Type (Optical Storage) | No optical drive |
| Monitor Type (Monitor) | None. |
| Video Interfaces (Graphics Controller) | VGA |
| Ethernet Ports (Networking) | 2 x Gigabit Ethernet |
| Data Link Protocol (Networking) | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol (Networking) | IPMI 2.0 |
| Remote Management Controller (Networking) | Integrated Remote Management Controller (iRMC S5) |
| Features (Networking) | Wake on LAN (WoL), PXE support |
| Bays (Expansion / Connectivity) | 4 (total) / 4 (free) x hot-swap 3.5" LFF 1 (total) / 1 (free) x external 5.25" |
| Slots (Expansion / Connectivity) | 3 (total) / 3 (free) x PCIe 3.0 x8 - low-profile 1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile 2 (total) / 2 (free) x PCIe 3.0 x16 - low-profile (2 processors must be installed) |
| Interfaces (Expansion / Connectivity) | 7 x USB 3.0 (2 front, 4 rear, 1 internal) 1 x VGA 1 x management - RJ-45 2 x LAN (Gigabit Ethernet) |
| Compliant Standards (Miscellaneous) | FCC Class A certified, BSMI, GS, CB, ICES-003 Class A, RoHS, WEEE, KC, VCCI V-3 Class A ITE, cCSAus, JIS C 61000-3-2, EAC, NMB-3 Class A, RCM |
| Device Type (Power) | Power supply - hot-plug |
| Power Redundancy (Power) | Optional |
| Power Redundancy Scheme (Power) | 1+1 (with optional power supply) |
| Installed Qty (Power) | 1 |
| Max Supported Qty (Power) | 2 |
| Voltage Required (Power) | AC 120/230 V (50/60 Hz) |
| Power Provided (Power) | 800 Watt |
| OS Provided (Operating System / Software) | No operating system |
| Software (Operating System / Software) | iRMC S5 Advanced Pack |
| Service & Support (Manufacturer Warranty) | Limited warranty - 3 years - on-site |
| Width (Dimensions & Weight) | 48.23 cm |
| Depth (Dimensions & Weight) | 77 cm |
| Height (Dimensions & Weight) | 8.66 cm |
| Min Operating Temperature (Environmental Parameters) | 5 °C |
| Max Operating Temperature (Environmental Parameters) | 45 °C |
| Humidity Range Operating (Environmental Parameters) | 10 - 85% (non-condensing) |
