Характеристики
| Type (General) | Server |
| Product Form Factor (General) | Rack-mountable - 1U |
| Built-in Devices (General) | Led panel |
| Embedded Security (General) | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability (General) | 2-way |
| Hot-Swap Bays Qty (General) | 8 |
| Localisation (General) | Region: Europe |
| CPU (Processor / Chipset) | Intel Xeon 6505P |
| Clock Speed (Processor / Chipset) | 2.2 GHz |
| Max Turbo Speed (Processor / Chipset) | 4.1 GHz |
| Number of Cores (Processor / Chipset) | 12-core |
| CPU Qty (Processor / Chipset) | 1 |
| Max CPU Qty (Processor / Chipset) | 2 |
| CPU Upgradability (Processor / Chipset) | Upgradable |
| Processor Main Features (Processor / Chipset) | Intel Turbo Boost Technology 2, Hyper-Threading Technology, 24 Threads, 150W TDP |
| Installed Size (Cache Memory) | L3 Cache - 48 MB |
| Cache Per Processor (Cache Memory) | 48 MB |
| Installed Size (RAM) | 64 GB (installed) / 8 TB (max) |
| Technology (RAM) | DDR5 SDRAM - Advanced ECC |
| Effective Memory Speed (RAM) | 6400 MT/s |
| Rated Memory Speed (RAM) | 6400 MT/s |
| Form Factor (RAM) | DIMM 288-pin |
| Slots (RAM) | 32 (Total) / 30 (empty) |
| Features (RAM) | Registered, slots 17 - 32 are available in two-processor configuration only, HPE SmartMemory |
| Configuration Features (RAM) | 2 x 32 GB |
| Type (Hard Drive) | No HDD |
| Type (Storage Controller) | 1 x RAID - OCP 3.0 |
| Storage Controller Name (Storage Controller) | HPE MR408i-o Gen11 SPDM |
| Channel Qty (Storage Controller) | 8 |
| Buffer Size (Storage Controller) | 4 GB |
| Type (Optical Storage) | No optical drive |
| Monitor Type (Monitor) | None. |
| Video Memory (Graphics Controller) | 16 MB |
| Video Interfaces (Graphics Controller) | VGA |
| Ethernet Controller (Networking) | Broadcom BCM57416 |
| Bays (Expansion / Connectivity) | 8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots (Expansion / Connectivity) | 1 (total) / 1 (free) x PCIe 5.0 x16 - full-height, 9.5" length (x16 mode) 2 (total) / 2 (free) x PCIe 5.0 x16 - half-height (x16 mode) 2 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0 |
| Interfaces (Expansion / Connectivity) | 1 x HPE iLO - Type C (1 in front) (service port) 1 x management (Gigabit Ethernet) - RJ-45 (1 front) (HPE iLO Service Port) 5 x USB 3.2 Gen 1 - Type A (1 front, 2 rear, 2 internal) 1 x VGA (1 rear) |
| Included Accessories (Miscellaneous) | 5 x standard fans |
| Compliant Standards (Miscellaneous) | ACPI 6.5, PCIe 5.0, UEFI, SMBIOS 3.7, UEFI 2.10, UEFI Class 3, Redfish API, AES, TLS v1.2, DMTF, Active Directory v1.0, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, IPv6 Ready |
| Device Type (Power) | Power supply - hot-plug |
| Power Redundancy (Power) | Yes |
| Power Redundancy Scheme (Power) | 1+1 |
| Installed Qty (Power) | 2 |
| Max Supported Qty (Power) | 2 |
| Voltage Required (Power) | AC 100-240 V |
| Power Provided (Power) | 1000 watt |
| 80 PLUS Certification (Power) | 80 PLUS Titanium |
| OS Provided (Operating System / Software) | No operating system |
| Software (Operating System / Software) | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE OneView Advanced |
| EPEAT Compliant (Sustainability Information) | EPEAT Silver |
| ENERGY STAR Certified (Sustainability Information) | Yes |
| ENERGY STAR Version (Sustainability Information) | 4.0 |
| Service & Support (Manufacturer Warranty) | Limited warranty - parts and labour - 3 years - on-site |
| Width (Dimensions & Weight) | 75.31 cm |
| Depth (Dimensions & Weight) | 43.46 cm |
| Height (Dimensions & Weight) | 4.29 cm |
| Min Operating Temperature (Environmental Parameters) | 10 °C |
| Max Operating Temperature (Environmental Parameters) | 35 °C |
| Humidity Range Operating (Environmental Parameters) | 8 - 90% RH (non-condensing) |
