Характеристики
| Type (General) | Server |
| Product Form Factor (General) | Rack-mountable - 2U |
| Built-in Devices (General) | Led panel |
| Embedded Security (General) | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability (General) | 1-way |
| Hot-Swap Bays Qty (General) | 8 |
| Localisation (General) | Region: Europe |
| CPU (Processor / Chipset) | Intel Xeon 6505P |
| Clock Speed (Processor / Chipset) | 2.2 GHz |
| Max Turbo Speed (Processor / Chipset) | 4.1 GHz |
| Number of Cores (Processor / Chipset) | 12-core |
| CPU Qty (Processor / Chipset) | 1 |
| Max CPU Qty (Processor / Chipset) | 1 |
| CPU Upgradability (Processor / Chipset) | Upgradable |
| Processor Main Features (Processor / Chipset) | Intel Turbo Boost Technology 2, Hyper-Threading Technology, 150W TDP, 24 Threads |
| Installed Size (Cache Memory) | L3 Cache - 48 MB |
| Cache Per Processor (Cache Memory) | 48 MB |
| Installed Size (RAM) | 64 GB (installed) / 8 TB (max) |
| Technology (RAM) | DDR5 SDRAM - Advanced ECC |
| Effective Memory Speed (RAM) | 6400 MT/s |
| Rated Memory Speed (RAM) | 6400 MT/s |
| Form Factor (RAM) | DIMM 288-pin |
| Slots (RAM) | 32 (Total) / 30 (empty) |
| Features (RAM) | Registered, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only |
| Configuration Features (RAM) | 2 x 32 GB |
| Type (Hard Drive) | No HDD |
| Type (Storage Controller) | 1 x RAID - OCP 3.0 |
| Storage Controller Name (Storage Controller) | HPE MR408i-o Gen11 SPDM |
| Channel Qty (Storage Controller) | 8 |
| Buffer Size (Storage Controller) | 4 GB |
| Type (Optical Storage) | No optical drive |
| Monitor Type (Monitor) | None. |
| Video Memory (Graphics Controller) | 16 MB |
| Video Interfaces (Graphics Controller) | VGA |
| Ethernet Controller (Networking) | Broadcom BCM57416 |
| Bays (Expansion / Connectivity) | 8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots (Expansion / Connectivity) | 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode) 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode) 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode) 1 (total) / 0 (free) x Open Compute Project mezzanine (OCP) 3.0 |
| Interfaces (Expansion / Connectivity) | 1 x USB-C (1 in front) (HPE iLO Service Port) 3 x USB 3.2 Gen 1 (1 front, 2 rear) 2 x USB 3.0 (2 internal) 1 x HPE iLO - RJ-45 (1 rear) (management port) 1 x VGA (1 rear) |
| Compliant Standards (Miscellaneous) | ACPI 6.5, PCIe 5.0, SMBIOS 3.7, UEFI 2.10, UEFI Class 3, Redfish API, AES, TLS v1.2, DMTF, APML, Active Directory v1.0, ASHRAE Class A3, ASHRAE Class A4, WEEE 2002/95/EC, ErP Lot 9, IPv6 Ready |
| Device Type (Power) | Power supply - hot-plug |
| Power Redundancy (Power) | Yes |
| Power Redundancy Scheme (Power) | 1+1 |
| Installed Qty (Power) | 2 |
| Max Supported Qty (Power) | 2 |
| Power Provided (Power) | 1000 watt |
| 80 PLUS Certification (Power) | 80 PLUS Titanium |
| OS Provided (Operating System / Software) | No operating system |
| Software (Operating System / Software) | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE iLO Advanced |
| ENERGY STAR Certified (Sustainability Information) | Yes |
| ENERGY STAR Version (Sustainability Information) | 4.0 |
| Service & Support (Manufacturer Warranty) | Limited warranty - parts and labour - 3 years - on-site |
| Width (Dimensions & Weight) | 72.7 cm |
| Depth (Dimensions & Weight) | 8.75 cm |
| Height (Dimensions & Weight) | 44.8 cm |
| Min Operating Temperature (Environmental Parameters) | 10 °C |
| Max Operating Temperature (Environmental Parameters) | 35 °C |
| Humidity Range Operating (Environmental Parameters) | 8 - 90% RH (non-condensing) |
