Type (General) | Server |
Product Form Factor (General) | Rack-mountable - 2U |
Built-in Devices (General) | Led panel |
Embedded Security (General) | Trusted Platform Module (TPM) Security Chip |
Server Scalability (General) | 2-way |
Hot-Swap Bays Qty (General) | 8 |
Localisation (General) | Region: Germany, Switzerland, Austria, France, United Kingdom, Scotland, Ireland |
CPU (Processor / Chipset) | Intel Xeon Silver 4510 |
Clock Speed (Processor / Chipset) | 2.4 GHz |
Max Turbo Speed (Processor / Chipset) | 4.1 GHz |
Number of Cores (Processor / Chipset) | 12-core |
CPU Qty (Processor / Chipset) | 1 |
Max CPU Qty (Processor / Chipset) | 2 |
CPU Upgradability (Processor / Chipset) | Upgradable |
Chipset Type (Processor / Chipset) | Intel C741 |
Installed Size (Cache Memory) | 30 MB |
Cache Per Processor (Cache Memory) | 30 MB |
Installed Size (RAM) | 64 GB (installed) / 8 TB (max) |
Technology (RAM) | DDR5 SDRAM |
Effective Memory Speed (RAM) | 4400 MHz |
Rated Memory Speed (RAM) | 5600 MHz |
Form Factor (RAM) | DIMM 288-pin |
Slots (RAM) | 32 (Total) / 30 (empty) |
Features (RAM) | HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only |
Configuration Features (RAM) | 2 x 32 GB |
Type (Hard Drive) | SSD - 2.5" |
Capacity (Hard Drive) | 2 x 960 GB |
Interface Type (Hard Drive) | SATA |
Type (Storage Controller) | 1 x RAID - OCP |
Controller Interface Type (Storage Controller) | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
Storage Controller Name (Storage Controller) | HPE MR408i-o Gen11 SPDM |
Channel Qty (Storage Controller) | 8 |
RAID Level (Storage Controller) | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
Buffer Size (Storage Controller) | 4 GB |
Type (Optical Storage) | No optical drive |
Monitor Type (Monitor) | None. |
Video Memory (Graphics Controller) | 16 MB |
Video Interfaces (Graphics Controller) | VGA |
Interface (Bus) Type (Networking) | Open Compute Project mezzanine (OCP) 3.0 |
Ethernet Ports (Networking) | 4 x Gigabit Ethernet |
Ethernet Controller (Networking) | Broadcom BCM5719 |
Data Link Protocol (Networking) | Ethernet, Fast Ethernet, Gigabit Ethernet |
Remote Management Controller (Networking) | Integrated Lights-Out 6 |
Features (Networking) | Wake on LAN (WoL), PXE support |
Compliant Standards (Networking) | OCP 3.0 |
Bays (Expansion / Connectivity) | 1 (total) / 1 (free) x external Universal Media Bay 8 (total) / 8 (free) x hot-swap 2.5" SFF |
Slots (Expansion / Connectivity) | 2 (total) / 2 (free) x FlexibleLOM 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode) 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode) |
Interfaces (Expansion / Connectivity) | 1 x USB 3.0 (1 in front) (HPE iLO Service Port) 4 x USB 3.0 (2 rear, 2 internal) 1 x HPE iLO - RJ-45 (1 rear) 1 x VGA (1 rear) 4 x LAN (Gigabit Ethernet) |
Included Accessories (Miscellaneous) | HPE Easy Install Rails |
Compliant Standards (Miscellaneous) | AES, TLS v1.2, ACPI 6.3, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, FIPS 140-2, low halogen, Triple DES, SMBIOS 3.2, Redfish API |
Manufacturer Selling Program (Miscellaneous) | HPE Smart Choice |
Device Type (Power) | Power supply - hot-plug |
Power Redundancy (Power) | Yes |
Power Redundancy Scheme (Power) | 1+1 |
Installed Qty (Power) | 2 |
Max Supported Qty (Power) | 2 |
Voltage Required (Power) | AC 100-240 V |
Power Provided (Power) | 1000 Watt |
80 PLUS Certification (Power) | 80 PLUS Titanium |
OS Provided (Operating System / Software) | No operating system |
OS Certified (Operating System / Software) | Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, Canonical Ubuntu, Oracle Linux |
Software (Operating System / Software) | HPE Server UEFI |
Service & Support (Manufacturer Warranty) | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
Width (Dimensions & Weight) | 44.8 cm |
Depth (Dimensions & Weight) | 72.7 cm |
Height (Dimensions & Weight) | 8.75 cm |
Weight (Dimensions & Weight) | 16 kg |
Min Operating Temperature (Environmental Parameters) | 10 °C |
Max Operating Temperature (Environmental Parameters) | 35 °C |
Humidity Range Operating (Environmental Parameters) | 8 - 90% RH (non-condensing) |
