Характеристики
| Type (General) | Server |
| Product Form Factor (General) | Rack-mountable - 1U |
| Built-in Devices (General) | 6 x fans |
| Embedded Security (General) | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability (General) | 2-way |
| Hot-Swap Bays Qty (General) | 8 |
| Localisation (General) | Region: EMEA |
| CPU (Processor / Chipset) | Intel Xeon Silver 4309Y |
| Clock Speed (Processor / Chipset) | 2.8 GHz |
| Max Turbo Speed (Processor / Chipset) | 3.6 GHz |
| Number of Cores (Processor / Chipset) | 8-core |
| CPU Qty (Processor / Chipset) | 1 |
| Max CPU Qty (Processor / Chipset) | 2 |
| Chipset Type (Processor / Chipset) | Intel C621A |
| Installed Size (Cache Memory) | L3 Cache - 12 MB |
| Cache Per Processor (Cache Memory) | 12 MB |
| Installed Size (RAM) | 32 GB (installed) / 8 TB (max) |
| Technology (RAM) | DDR4 SDRAM - ECC |
| Effective Memory Speed (RAM) | 2667 MHz |
| Rated Memory Speed (RAM) | 1334 MHz |
| Form Factor (RAM) | DIMM 288-pin |
| Slots (RAM) | 32 (Total) / 31 (empty) |
| Features (RAM) | Registered, Memory Mirroring, mixing of different types of memory modules is not supported, slots 17 - 32 are available in two-processor configuration only |
| Configuration Features (RAM) | 1 x 32 GB |
| Type (Hard Drive) | No HDD |
| Type (Storage Controller) | 1 x RAID - PCIe 3.0 x8 |
| Controller Interface Type (Storage Controller) | SATA 6Gb/s / SAS 12Gb/s |
| Storage Controller Name (Storage Controller) | ThinkSystem RAID 930-8i |
| Channel Qty (Storage Controller) | 8 |
| RAID Level (Storage Controller) | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60 |
| Buffer Size (Storage Controller) | 2 GB |
| Type (Optical Storage) | No optical drive |
| Monitor Type (Monitor) | None. |
| Graphics Processor (Graphics Controller) | Matrox G200 |
| Video Memory (Graphics Controller) | 16 MB |
| Video Interfaces (Graphics Controller) | VGA |
| Remote Management Controller (Networking) | XClarity Controller (XCC) Enterprise |
| Bays (Expansion / Connectivity) | 8 (total) / 8 (free) x hot-swap 2.5" |
| Slots (Expansion / Connectivity) | 1 (total) / 1 (free) x PCIe 4.0 x16 / Open Compute Project mezzanine (OCP) 3.0 2 (total) / 2 (free) x PCIe 4.0 x16 (low-profile) |
| Interfaces (Expansion / Connectivity) | 4 x USB 3.1 Gen 1 (1 front, 3 rear) 1 x USB 2.0 (1 in front) 2 x VGA (1 front, 1 rear) 1 x management 1 x diagnostics 1 x USB 3.1 Gen 1 (1 internal) |
| Theft/Intrusion Protection (Miscellaneous) | Chassis intrusion switch |
| Compliant Standards (Miscellaneous) | BSMI CNS 13438 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, CCC, FCC Part 15 A, GB 17625.1, CECP, VCCI Class A, EN 50581, GB 4943.1, KN35, UL 2819, AS/NZS CISPR 32 Class A, KN32 Class A, CNS 14336-1, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 62368-1, EN 55035, CISPR 35, CELP, HJ 2507-2011, CNS 15663 section 5, TP EAC 037/2016, AS/NZS 62368.1, ANSI/UL 62368-1, ICES-003 issue 7 Class A, GB/T9254, CQC3135 |
| Device Type (Power) | Power supply - hot-plug |
| Power Redundancy (Power) | Optional |
| Power Redundancy Scheme (Power) | 1+1 (with optional power supply) |
| Installed Qty (Power) | 1 |
| Max Supported Qty (Power) | 2 |
| Voltage Required (Power) | AC 100-240 V (50/60 Hz) |
| Power Provided (Power) | 1100 Watt |
| 80 PLUS Certification (Power) | 80 PLUS Titanium |
| OS Provided (Operating System / Software) | No operating system |
| EPEAT Compliant (Sustainability Information) | EPEAT Bronze |
| ENERGY STAR Certified (Sustainability Information) | Yes |
| ENERGY STAR Version (Sustainability Information) | 3.0 |
| Service & Support (Manufacturer Warranty) | Limited warranty - 3 years - on-site - response time: next business day |
| Dimensions & Weight Details (Dimensions & Weight) | 58.7 cm - 99.8 cm - 22.5 cm |
| Width (Dimensions & Weight) | 44 cm |
| Depth (Dimensions & Weight) | 77.3 cm |
| Height (Dimensions & Weight) | 4.3 cm |
| Weight (Dimensions & Weight) | 20.8 kg |
