Характеристики
| Type (General) | Server |
| Product Form Factor (General) | Tower - 4U |
| Embedded Security (General) | Trusted Platform Module (TPM 1.2 and TPM 2.0) |
| Server Scalability (General) | 2-way |
| Front Accessible Bays Qty (General) | 2 |
| Hot-Swap Bays Qty (General) | 8 |
| Localisation (General) | Region: EMEA |
| CPU (Processor / Chipset) | Intel Xeon Silver 4210R |
| Clock Speed (Processor / Chipset) | 2.4 GHz |
| Max Turbo Speed (Processor / Chipset) | 3.2 GHz |
| Number of Cores (Processor / Chipset) | 10-core |
| CPU Qty (Processor / Chipset) | 1 |
| Max CPU Qty (Processor / Chipset) | 2 |
| Chipset Type (Processor / Chipset) | Intel C621 |
| Installed Size (Cache Memory) | L3 Cache - 13.75 MB |
| Cache Per Processor (Cache Memory) | 13.75 MB |
| Installed Size (RAM) | 32 GB (installed) / 768 GB (max) |
| Technology (RAM) | DDR4 SDRAM - ECC |
| Effective Memory Speed (RAM) | 2400 MHz |
| Rated Memory Speed (RAM) | 1200 MHz |
| Form Factor (RAM) | DIMM 288-pin |
| Slots (RAM) | 12 (Total) / 11 (empty) |
| Features (RAM) | Registered, Memory Mirroring, Memory Sparing, low-voltage, mixing of different types of memory modules is not supported, slots 7 - 12 are available in two-processor configuration only, TruDDR4, 6-channel memory architecture, Single Device Data Correction (SDDC) |
| Configuration Features (RAM) | 1 x 32 GB |
| Type (Hard Drive) | No HDD |
| Type (Storage Controller) | 1 x RAID - PCIe 3.0 x8 |
| Controller Interface Type (Storage Controller) | SATA 6Gb/s / SAS 12Gb/s |
| Storage Controller Name (Storage Controller) | ThinkSystem RAID 930-8i |
| Channel Qty (Storage Controller) | 8 |
| RAID Level (Storage Controller) | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60 |
| Buffer Size (Storage Controller) | 2 GB |
| Type (Optical Storage) | No optical drive |
| Monitor Type (Monitor) | None. |
| Graphics Processor (Graphics Controller) | Matrox G200 |
| Video Memory (Graphics Controller) | 16 MB |
| Video Interfaces (Graphics Controller) | VGA |
| Ethernet Ports (Networking) | 2 x Gigabit Ethernet |
| Ethernet Controller (Networking) | Intel X722 |
| Data Link Protocol (Networking) | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol (Networking) | SNMP 3, CIM, IPMI 2.0 |
| Remote Management Controller (Networking) | XClarity Controller (XCC) Enterprise |
| Features (Networking) | Wake on LAN (WoL) |
| Bays (Expansion / Connectivity) | 2 (total) / 2 (free) x external 5.25" x 1/2H 8 (total) / 8 (free) x hot-swap 2.5" |
| Slots (Expansion / Connectivity) | 1 PCIe 3.0 x8 - half-length, full-height 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height, double-width 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x8 mode, 2 processors must be installed) 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height, double-width (2 processors must be installed) 1 PCIe 3.0 x8 - full-length, full-height |
| Interfaces (Expansion / Connectivity) | 4 x USB 3.0 (1 front, 2 rear, 1 internal) 5 x USB 2.0 (1 front, 4 rear) 1 x VGA 1 x management - RJ-45 2 x LAN (Gigabit Ethernet) - RJ-45 |
| Theft/Intrusion Protection (Miscellaneous) | Security lock slot (cable lock sold separately) |
| Security Slot Type (Miscellaneous) | Kensington security slot |
| Compliant Standards (Miscellaneous) | TUV GS, BSMI CNS 13438 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, CB, AS/NZS 60950-1, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, CSA C22.2 No. 60950-1, GB 17625.1, GB 9254 Class A, VCCI Class A, GB 4943.1, BSMI CNS 14336-1, NOM-019, EK1-ITB2000, Energy-Related Products (ErP) Lot 3, KN35, ICES-003 issue 6 Class A, AS/NZS CISPR 32 Class A, KN32 Class A, EN 55032 Class A, CISPR 32 Class A, EN 62368-1:2014, BSMI CNS 15663, TR CU 020/2011, TR CU 004/2011, JESL |
| Device Type (Power) | Power supply - hot-plug |
| Power Redundancy (Power) | Optional |
| Power Redundancy Scheme (Power) | 1+1 (with optional power supply) |
| Installed Qty (Power) | 1 |
| Max Supported Qty (Power) | 2 |
| Voltage Required (Power) | AC 100-240 V (50/60 Hz) |
| Power Provided (Power) | 750 Watt |
| 80 PLUS Certification (Power) | 80 PLUS Titanium |
| OS Provided (Operating System / Software) | No operating system |
| ENERGY STAR Certified (Sustainability Information) | Yes |
| ENERGY STAR Version (Sustainability Information) | 3.0 |
| Service & Support (Manufacturer Warranty) | Limited warranty - 3 years - on-site - response time: next business day |
| Width (Dimensions & Weight) | 17.6 cm |
| Depth (Dimensions & Weight) | 66 cm |
| Height (Dimensions & Weight) | 43.8 cm |
| Weight (Dimensions & Weight) | 36 kg |
| Shipping Width (Dimensions & Weight (Shipping)) | 57.4 cm |
| Shipping Depth (Dimensions & Weight (Shipping)) | 98.2 cm |
| Shipping Height (Dimensions & Weight (Shipping)) | 37.2 cm |
