Характеристики
| Device Type (General) | Switch - 12 ports - L3 - Managed |
| Enclosure Type (General) | Side to side airflow rack-mountable 1U |
| Subtype (General) | 10 Gigabit Ethernet |
| Ports (General) | 10 x 10/100/1000 (8 PoE+) + 2 x 10 Gigabit SFP+ |
| Power Over Ethernet (PoE) (General) | PoE+ |
| PoE Budget (General) | 240 W |
| Performance (General) | Switching capacity: 60 Gbps Firewall throughput (64-byte packet size): 44.64 Mpps Latency (1 Gbps): < 2.14 µs Latency (10 Gbps): < 0.84 µs |
| Capacity (General) | VLANs supported: 4093 ARP entries: 4000 Multicast entries (IPv4): 512 Multicast entries (IPv6): 128 Jumbo frame size: up to 12000 IGMP multicast groups: 2000 MSTP instances: 16 PVST instances: 32 |
| MAC Address Table Size (General) | 16K entries |
| Routing Protocol (General) | RIP, IGMP, IGMPv2, IGMPv3, MLDv2, static IPv4 routing, static IPv6 routing, PIM-DM, PIM-SM, PIM-SSM |
| Remote Management Protocol (General) | CLI, SNMP, HTTPS, Telnet, SSH, RADIUS, TACACS+, RMON 1, RMON 2, RMON 9 |
| Encryption Algorithm (General) | TLS 1.2, SSL 3.0 |
| Features (General) | 16MB packet buffer, RSPAN, PIM, DHCP server, policy based routing, LLDP-MED, MVRP, STP support, RSTP, BPDU, STRG, VLAN support, GVRP, GMRP, LACP, LAG, Private VLAN, DHCP snooping, DAI, IP source guard, DHCP relay, AAA, sFlow, QoS, DoS attack prevention |
| Compliant Standards (General) | IEEE 802.1ak, IEEE 802.1as, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at |
| Processor (General) | X ARM A9: 1.25 GHz |
| RAM (General) | 2 GB |
| Flash Memory (General) | 256 MB |
| Interfaces (Expansion / Connectivity) | 10 x 10/100/1000 Base-T RJ-45 8 ports (PoE+) 2 x 10GBase-X SFP+ 1 x management (Gigabit LAN) RJ-45 1 x console RJ-45 1 x USB Type A 1 x console (USB) Type C |
| Power Device (Power) | Internal power supply |
| Installed Qty (Power) | 1 |
| Voltage Required (Power) | AC 110 V |
| Power Consumption Operational (Power) | 25 Watt |
| Power Consumption Stand by (Power) | 12.96 Watt |
| Included Accessories (Miscellaneous) | Mounting brackets, 2 x SFP slot caps, foot pad set |
| Cables Included (Miscellaneous) | Console cable USB-C to USB-A cable |
| Rack Mounting Kit (Miscellaneous) | Included |
| Compliant Standards (Miscellaneous) | IEEE 1588, AN/NZS 60950.1:2015, ANSI C63.4:2014, AS/NZS CISPR32:2013 Class A, CCC, CISPR 32:2012, CNS 13438 Class A, CNS 14336-1, EN 55024:2010, EN 55032:2012+AC:2013 Class A, EN 60950-1:2006+A1:2010+A11:2009+A2:2013+A12:2011, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, FCC CFR47 Part 15 B Class A, GB 4943.1-2011, GB/T9254-2008 Class A, ICES-003:2016 issue 6 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, IEC60950/EN60950, VCCI-CISPR 32:2016 Class A, YD/T993-1998 |
| Localisation (Miscellaneous) | Europe |
| Width (Dimensions & Weight) | 44 cm |
| Depth (Dimensions & Weight) | 20 cm |
| Height (Dimensions & Weight) | 4.32 cm |
| Weight (Dimensions & Weight) | 2.9 kg |
| Service & Support (Manufacturer Warranty) | Limited warranty - lifetime |
| Min Operating Temperature (Environmental Parameters) | 0 °C |
| Max Operating Temperature (Environmental Parameters) | 45 °C |
| Humidity Range Operating (Environmental Parameters) | 90% (non-condensing) |
| Min Storage Temperature (Environmental Parameters) | -20 °C |
| Max Storage Temperature (Environmental Parameters) | 70 °C |
| Humidity Range Storage (Environmental Parameters) | 95% (non-condensing) |
