Характеристики
| Device Type (General) | Wireless router - 3-port switch (integrated) |
| Enclosure Type (General) | DIN rail mountable |
| Connectivity Technology (General) | Wired, wireless |
| Data Link Protocol (General) | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Ethernet, Fast Ethernet, RS-232, RS-485 |
| Frequency Band (General) | 2.4 GHz |
| Capacity (General) | Simultaneous connections: 100 |
| Network / Transport Protocol (General) | TCP, UDP, IPv4, IPv6, NTP, DNS, SFTP, FTP, ARP, PPPoE, DHCP, Telnet, PPTP, L2TPv3, WireGuard, OpenVPN |
| Routing Protocol (General) | BGP, OSPFv2, RIP-1, RIP-2, NHRP, EIGRP, VRRP |
| Remote Management Protocol (General) | ICMP, HTTP, HTTPS, SMTP, SSH, SMPP, SMNP, MQTT, SSH-2, SNMP 1, SNMP 2, SNMP 3, TR-069, BACnet, Kinesis |
| Encryption Algorithm (General) | WPA3-EAP, WPA3-SAE, WPA2-Enterprise, PEAP, WPA2-PSK, WEP, AES-CCMP, TKIP, SSL, TLS, DES, DESX, IKEv1, IKEv2, 128-bit AES-CBC, 192-bit AES-CBC, 256-bit AES-CBC, CAST5 |
| Authentication Method (General) | Radio Service Set ID (SSID), RADIUS, X.509 certificates, TACACS+ |
| Features (General) | RSSI support, USSD support, white list, black list, band management, auto APN, bridge mode, Access Point operational mode, Auto Cipher modes, client separation, Stealth Mode, Fast Roaming, MAC address filtering, Captive Portal, RADIUS Server, static routing, policy based routing, WOL, port forwarding, DHCP relay, load balancing, QoS, SQM, SSHFS support, auto-uplink (auto MDI/MDI-X), PSK, IPSec NAT-T, DDos attack prevention, port scan prevention, VLAN support, mobile quota control, Web Filtering, GRE tunneling, Modbus compatible, DNP3 outstation, DLMS support, FOTA, SNMP trap, Teltonika RMS, GPS/GLONASS/Galileo/BeiDou/QZSS support, NTRIP, passive PoE supported, automated failover |
| Compliant Standards (General) | IEEE 802.11r, UPnP, IEEE 802.11e, IEEE 802.3, IEEE 802.3u, IP30, UKCA, RCM, CB, E Mark, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019+A2:2021, EN IEC 61000-3-2:2019+A1:2021, EN 301 489-1 V2.2.3, EN 301 489-17 V3.2.4, EN 301 489-19 V2.2.0, EN 301 489-52 V1.2.1, EN 61000-4-2:2009, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, EN 61000-4-3:2020, EN 62311, IEC 62368-1:2018, EN 301 908-1, EN 301 908-2, EN 301 908-13, EN 300 328 |
| Processor (General) | 1 x MediaTek MIPS 24Kec 580 MHz |
| RAM (General) | 128 MB DDR2 SDRAM |
| Flash Memory (General) | 16 MB |
| Built-in Devices (General) | GNSS receiver |
| Status Indicators (General) | Connection status, signal strength, Ethernet link/activity, power |
| Type (Communications) | Wireless cellular modem |
| Mobile Communication Protocol (Communications) | FDD LTE, TDD LTE |
| Generation (Communications) | 4G, 2G, 3G |
| Cellular Band (Communications) | LTE B1, LTE B3, LTE B7, LTE B8, LTE B20, LTE B28, LTE B38, LTE B40, LTE B41 |
| Max Transfer Rate (Communications) | 150 Mbps |
| VoIP Protocols (IP Telephony) | SIP, H.323 |
| Internet of Things (IoT) Compatible (Internet of Things (IoT)) | Yes |
| Platform (Internet of Things (IoT)) | Clouds of Things, ThingWorx, Cumulocity, Azure IoT Hub |
| Interfaces (Expansion / Connectivity) | WAN: 1 x 10Base-T/100Base-TX - RJ-45 LAN: 3 x 10Base-T/100Base-TX - RJ-45 Serial: 1 x RS-232 - 9 pin D-Sub (DB-9) Serial: 1 x RS-485 USB 2.0: 1 x 4 pin USB Type A Antenna: 2 x SMA - LTE Antenna: 2 x RP-SMA - Wi-Fi Antenna: 1 x SMA - GNSS aerial Input / output |
| Expansion Slots (Expansion / Connectivity) | 2 (total) / 2 (free) x Mini-SIM |
| Aerial (Aerial) | External detachable |
| Antenna Qty (Aerial) | 5 |
| Power Device (Power) | External power adapter - 9 Watt |
| Included Accessories (Miscellaneous) | Power adapter (EU), 2 x LTE aerials, 2 x WiFi aerials, GNSS aerial, RS-485 connector, I/O connector, SIM card adapter kit |
| Cables Included (Miscellaneous) | 1 x network cable - 1.5 m |
| Localisation (Miscellaneous) | Europe (excluding Belarus, Russia), Middle East, Africa, Thailand |
| OS Provided (Software / System Requirements) | RutOS |
| Width (Dimensions & Weight) | 10.95 cm |
| Depth (Dimensions & Weight) | 10 cm |
| Height (Dimensions & Weight) | 5 cm |
| Weight (Dimensions & Weight) | 295 g |
| Min Operating Temperature (Environmental Parameters) | -40 °C |
| Max Operating Temperature (Environmental Parameters) | 75 °C |
| Humidity Range Operating (Environmental Parameters) | 10 - 90% (non-condensing) |
