Характеристики
| Device Type (General) | Wireless router - 3-port switch (integrated) |
| Enclosure Type (General) | DIN rail mountable, surface-mountable, wall-mountable |
| Connectivity Technology (General) | Wired, wireless |
| Data Link Protocol (General) | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency Band (General) | 2.4 GHz |
| Capacity (General) | Concurrent connections: 100 |
| Network / Transport Protocol (General) | TCP/IP, PPTP, UDP/IP, L2TP, NTP, ICMP/IP, IPSec, ARP, PPPoE, SMTP, FTP, DHCP, DNS, DDNS, HTTP, HTTPs, IPv4, IPv6, Telnet |
| Routing Protocol (General) | BGP, OSPFv2, RIP-1, RIP-2, NHRP, VRRP, GRE, static IP routing |
| Remote Management Protocol (General) | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI, TR-069, JSON-RPC, Modbus, NTP, MQTT, RADIUS |
| Encryption Algorithm (General) | DES, Triple DES, RC2, CAST5, TLS, SSL 3.0, PEAP, TKIP, WPA-PSK, AES-CCMP, 128-bit AES, 192-bit AES, 256-bit AES, WPA2-PSK, WPA2-Enterprise, IKEv2, WEP, 256-bit AES-CBC, 128-bit AES-CBC, 192-bit AES-CBC, IKEv1 |
| Authentication Method (General) | Secure Shell (SSH), RADIUS, X.509 certificates, Radio Service Set ID (SSID), Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Features (General) | Firewall protection, NAT support, VPN support, load balancing, WOL, auto-uplink (auto MDI/MDI-X), ALG support, E-mail alert, MAC address filtering, Access Point operational mode, firmware upgradable, DDos attack prevention, WMM support, event log, QoS, IPSec NAT-T, DMVPN, SMS alert, port forwarding, reset button, DHCP relay, SNMP trap, DIN rail mountable, GRE tunneling, FOTA, tagged VLAN, SYN Flooding, Captive Portal, system log, Web Filtering, Hotspot Access Point Capability, DMZ support, port-based VLAN, black list, white list, bridge mode, PPP, OpenVPN client, OpenVPN server, aluminium housing, VoIP passthrough support |
| Compliant Standards (General) | IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11e, IEEE 802.11n, UPnP, CCC, FCC, RoHS, FCC CFR47 Part 15, WEEE, ANATEL, FCC CFR47 Part 15 C, REACH, PTCRB, DNV, GCF, IP30, EAC, EN 61000-4-2:2009, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-11:2004, RCM, TRA, EN 61000-4-3:2006+A1:2008+A2:2010, EN 62311:2008, EN 61000-4-5:2014, SDPPI, IEC60950-1:2005, Second edition + Am1:2009 + Am2:2013, ANSI C63.4-2014, AS/NZS 60950-1:2015, EN 300 328 V2.1.1, RED, EN 301 489-1 V2.2.0, NBTC, EN 301 489-52 V1.1.0, EN 301 489-17 V3.2.0, AS/NZS 4268:2017, Postel, EN 301 489-19 V2.1.0, EN 301 511 V12.5.1, EN 301 908-1 V11.1.1, EN 301 908-2 V11.1.1, EN 301 908-13 V11.1.1, EN 61000-4-4:2012, ISO 7632-2:2004, AS/ACIF S042.3:2005, AS/CA S042.4:2018, AS/CA S042.1:2018, FCC CFR47 Part 22H, FCC CFR47 Part 24E, FCC CFR47 Part 27, EN 50665:2017, FCC CFR47 Part 1 1.1310, EN 60529:1999+A1+AC:2002, EN 60068-2-6:2008 |
| Processor (General) | MediaTek MIPS 24Kec 580 MHz |
| RAM (General) | 128 MB DDR2 SDRAM |
| Flash Memory (General) | 16 MB |
| Status Indicators (General) | Power, signal strength, WAN, LAN |
| Type (Communications) | Wireless cellular modem |
| Mobile Communication Protocol (Communications) | 4G LTE |
| Generation (Communications) | 3G, 4G |
| Max Transfer Rate (Communications) | 150 Mbps |
| VoIP Protocols (IP Telephony) | H.323, SIP |
| Internet of Things (IoT) Compatible (Internet of Things (IoT)) | Yes |
| Platform (Internet of Things (IoT)) | Clouds of Things, ThingWorx, Azure IoT Hub, AWS IoT Core |
| Communications Technology (Internet of Things (IoT)) | LTE Cat 4 |
| Interfaces (Expansion / Connectivity) | LAN: 3 x 10Base-T/100Base-TX - RJ-45 WAN / LAN: 1 x 10Base-T/100Base-TX - RJ-45 Antenna: 2 x SMA - LTE Antenna: 2 x RP-SMA - Wi-Fi 1 x DI/DO - 4 pin power |
| Expansion Slots (Expansion / Connectivity) | 2 (total) / 2 (free) x Mini-SIM |
| Aerial (Aerial) | External detachable |
| Antenna Qty (Aerial) | 4 |
| Configuration Details (Aerial) | 2 detachable external LTE antennas, 2 external Wi-Fi antennas |
| Power Device (Power) | External power adapter (not included) |
| Voltage Required (Power) | DC 9 - 57 V |
| Included Accessories (Miscellaneous) | 2 x LTE aerials, 2 x WiFi aerials, power adapter (EU) |
| OS Provided (Software / System Requirements) | RutOS |
| Width (Dimensions & Weight) | 11 cm |
| Depth (Dimensions & Weight) | 10 cm |
| Height (Dimensions & Weight) | 5 cm |
| Weight (Dimensions & Weight) | 287 g |
| Service & Support (Manufacturer Warranty) | Limited warranty - 2 years |
| Min Operating Temperature (Environmental Parameters) | -40 °C |
| Max Operating Temperature (Environmental Parameters) | 75 °C |
| Humidity Range Operating (Environmental Parameters) | 10 - 90% (non-condensing) |
