Характеристики
| Device Type (General) | Wireless router - 3-port switch (integrated) |
| Enclosure Type (General) | DIN rail mountable |
| Connectivity Technology (General) | Wired, wireless |
| Data Link Protocol (General) | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Ethernet, Fast Ethernet |
| Frequency Band (General) | 2.4 GHz |
| Capacity (General) | Concurrent connections: 100 |
| Network / Transport Protocol (General) | TCP/IP, PPTP, UDP/IP, L2TPv3, NTP, ICMP/IP, IPSec, ARP, PPPoE, SMTP, FTP, DHCP, DNS, DDNS, HTTP, HTTPs, IPv4, IPv6, Telnet, OpenVPN, WireGuard |
| Routing Protocol (General) | Static IP routing, BGP, OSPFv2, RIP-1, RIP-2, NHRP, VRRP, GRE |
| Remote Management Protocol (General) | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI, TR-069, JSON-RPC, Modbus, NTP, MQTT, RADIUS |
| Encryption Algorithm (General) | WPA2-Enterprise, PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK, AES-CCMP, TKIP, SSL 3.0, TLS, DES, RC2, DESX, CAST5, 128-bit AES-CBC, 192-bit AES-CBC, 256-bit AES-CBC, IKEv1, IKEv2 |
| Authentication Method (General) | Radio Service Set ID (SSID), X.509 certificates, RADIUS |
| Features (General) | Firewall protection, NAT support, VPN support, load balancing, WOL, auto-uplink (auto MDI/MDI-X), ALG support, E-mail alert, MAC address filtering, Access Point operational mode, firmware upgradable, DDos attack prevention, WMM support, event log, QoS, IPSec NAT-T, DMVPN, SMS alert, port forwarding, reset button, DHCP relay, SNMP trap, DIN rail mountable, GRE tunneling, FOTA, tagged VLAN, SYN Flooding, Captive Portal, system log, Web Filtering, Hotspot Access Point Capability, DMZ support, port-based VLAN, black list, white list, bridge mode, PPP, OpenVPN client, OpenVPN server, aluminium housing, VoIP passthrough support |
| Compliant Standards (General) | IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11e, IEEE 802.11n, UPnP, IP30, RED, UKCA, CB, EN 301 489-1 V2.2.3, ETSI EN 301 489-17 V3.2.4, EN 301 489-19 V2.2.0, EN 301 489-52 V1.2.0, EN 55032:2015+A1:2020, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019, EN IEC 61000-3-2:2019, EN 61000-4-2:2009, EN 61000-4-3:2020, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2009, EN IEC 61000-4-11:2020, EN 300 328 V2.2.2, EN 301 908-1 V13.1.1, EN 301 908-2 V13.1.1, EN 301 908-13 V13.1.1, EN 303 413 V1.1.1, EN IEC 62311:2020, AS/NZS 60950-1:2015, IEC 62368-1:2018, EN IEC 62368-1:2020+A11:2020 |
| Processor (General) | 1 x MediaTek MIPS 24KC 580 MHz |
| RAM (General) | 128 MB DDR2 SDRAM |
| Flash Memory (General) | 16 MB |
| Built-in Devices (General) | GNSS receiver |
| Status Indicators (General) | Power, signal strength, WAN, LAN |
| Type (Communications) | Wireless cellular modem |
| Mobile Communication Protocol (Communications) | GSM, FDD LTE, TDD LTE |
| Generation (Communications) | 3G, 4G |
| Cellular Band (Communications) | LTE B1, LTE B12, LTE B13, LTE B18, LTE B19, LTE B2, LTE B20, LTE B25, LTE B26, LTE B28, LTE B3, LTE B38, LTE B39, LTE B4, LTE B40, LTE B41, LTE B5, LTE B7, LTE B8 |
| Max Transfer Rate (Communications) | 150 Mbps |
| VoIP Protocols (IP Telephony) | H.323, SIP |
| Internet of Things (IoT) Compatible (Internet of Things (IoT)) | Yes |
| Platform (Internet of Things (IoT)) | Clouds of Things, ThingWorx, Cumulocity, Azure IoT Hub |
| Communications Technology (Internet of Things (IoT)) | LTE Cat 4 |
| Interfaces (Expansion / Connectivity) | WAN: 1 x 10Base-T/100Base-TX - RJ-45 LAN: 3 x 10Base-T/100Base-TX - RJ-45 Serial: 1 x RS-232 - 9 pin D-Sub (DB-9) Serial: 1 x RS-485 USB 2.0: 1 x 4 pin USB Type A Antenna: 2 x SMA - LTE Antenna: 2 x RP-SMA - Wi-Fi Antenna: 1 x SMA - GNSS aerial Input / output |
| Expansion Slots (Expansion / Connectivity) | 2 (total) / 2 (free) x SIM |
| Aerial (Aerial) | External detachable |
| Antenna Qty (Aerial) | 5 |
| Power Device (Power) | External power adapter - 9 Watt |
| Voltage Required (Power) | AC 100-240 V (50/60 Hz) |
| Included Accessories (Miscellaneous) | 2 x LTE aerials, 2 x WiFi aerials, GNSS aerial, RS-485 connector, I/O connector, SIM card adapter kit, power adapter (EU) |
| Cables Included (Miscellaneous) | 1 x network cable - 1.5 m |
| Localisation (Miscellaneous) | Global (excluding Belarus, Iran, Russia) |
| OS Provided (Software / System Requirements) | RutOS |
| Width (Dimensions & Weight) | 11 cm |
| Depth (Dimensions & Weight) | 10 cm |
| Height (Dimensions & Weight) | 5 cm |
| Weight (Dimensions & Weight) | 287 g |
| Service & Support (Manufacturer Warranty) | Limited warranty - 2 years |
| Min Operating Temperature (Environmental Parameters) | -40 °C |
| Max Operating Temperature (Environmental Parameters) | 75 °C |
| Humidity Range Operating (Environmental Parameters) | 10 - 90% (non-condensing) |
