Характеристики
| Device Type (General) | Switch - 8 ports - Managed |
| Enclosure Type (General) | DIN rail mountable |
| Subtype (General) | Gigabit Ethernet |
| Ports (General) | 8 x 10/100/1000 (PoE+) + 2 x SFP |
| Power Over Ethernet (PoE) (General) | PoE+ |
| PoE Budget (General) | 240 W |
| Performance (General) | Non-blocking bandwidth: 20 Gbps |
| Capacity (General) | Packet buffer size: 512 KB |
| MAC Address Table Size (General) | 8K entries |
| Jumbo Frame Support (General) | 10000 bytes |
| Remote Management Protocol (General) | SNMP 2, SNMP 3 |
| Features (General) | Auto-uplink (auto MDI/MDI-X), PROFINET, EtherNet/IP enabled, LLDP support, loop protection, VLAN support, STP support, RSTP support, DHCP server, DHCP client, port isolation, port mirroring, static routing, DHCPv6 client, port-based priority, DSCP prioritisation, ToS, SP, WFQ, WRR, traffic shaping, FOTA |
| Compliant Standards (General) | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3az, IEEE 802.3af, IEEE 802.3at |
| RAM (General) | 128 MB DDR3 SDRAM |
| Flash Memory (General) | 16 MB |
| Status Indicators (General) | Power, AUX, port status |
| Interfaces (Expansion / Connectivity) | 8 x 1000Base-T RJ-45 30 W 2 x LAN SFP |
| Voltage Required (Power) | DC 7 - 57 V |
| Compliant Standards (Miscellaneous) | IP30, UKCA, RCM, ANRT, FCC, IC, CB, RoHS, REACH, EN 55032:2015+A11:2020+A1:2020, EN 55035:2017+A11:2020, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013 + A1:2019 + A2:2021, EN 61000-4-2:2009, EN 61000-4-3:2020, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, EN IEC 62368-1:2020+A11:2020, AS/NZS 62368-1:2022, IEC 62368-1:2018 |
| Width (Dimensions & Weight) | 13.2 cm |
| Depth (Dimensions & Weight) | 12.22 cm |
| Height (Dimensions & Weight) | 4.42 cm |
| Weight (Dimensions & Weight) | 610 g |
| Min Operating Temperature (Environmental Parameters) | -40 °C |
| Max Operating Temperature (Environmental Parameters) | 75 °C |
| Humidity Range Operating (Environmental Parameters) | 10 - 90% (non-condensing) |
