| Суич, тип |
Fixed Port |
| Общ брой портове |
8 |
| Основни портове, тип |
8x10/100/1000Base-T |
| Power Over Ethernet (PoE) |
No |
| Uplink портове |
0 |
| Свободни (10GB) слотове |
No |
| Управление |
Built-in Web-based browser for simple configuration and management; Network Management: SNMP v1, v2, v3; RMON (1, 2, 3, 9); ICMP echo/echo reply; Syslog; IEEE 802.1AB LLDP; IEEE 802.1AB LLDP-MED |
| Stackable |
No |
| Fans |
Fanless design |
| Захранване |
Input voltage of AC: 100 - 240 V AC, 50/60 Hz; Max. power consumption: 6.2 (watt) |
| Routing |
Layer 2 Only |
| Памет (Flash, RAM) |
Packet Buffer: 525 KB |
| Капацитет за маршрутизиране/превключване, Gbps |
16 Gbps |
| Пропускателна способност, Mpps |
11.9 Mpps |
| MAC адреси |
8000 MAC address table size |
| VLAN (брой, стандарти) |
Port-based VLAN, IEEE 802.1Q VLAN tagging, IEEE 802.3ad LACP, Guest VLAN, Voice VLAN |
| QoS |
IEEE 802.1p priority queues per port, IEEE 802.1p Queuing method (scheduler), Input priority mapping, Rate limiting per port (ingress/egress) |
| L2 мрежови стандарти |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x flow control, IEEE 802.3az EEE support, IEEE 802.1p CoS support, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s |
| L3 мрежови стандарти |
- |
| IPv6 functionality |
IPv6 over Ethernet, Dual-stack, ICMPv6, Neighbor discovery, Auto configuration, Static IPv6 address and prefix length, Static IPv6 default gateway, IPv6 duplicate address detection |
| Сигурност |
IEEE 802.1x, Port security, Layer 2 MAC filtering, Static MAC forwarding, RADIUS, TACACS+, SSL, Management VLAN, CPU defense engine, DoS prevention |
| Размери (Ш, Д, В), mm |
250 x 104 x 27 |
| Опция за монтаж |
Desktop |
