| Суич, тип |
Fixed Port |
| Общ брой портове |
8 |
| Основни портове, тип |
8x10/100/1000Base-T |
| Power Over Ethernet (PoE) |
8x 802.3at PoE ports, Total PoE budget (W): 60W |
| Uplink портове |
0 |
| Свободни (10GB) слотове |
No |
| Управление |
Standalone management by Web; Management through Web, SNMP; Remote firmware upgrade by FTP/Web; DHCP; NTP; Port mirroring |
| Stackable |
No |
| Fans |
Fanless design |
| Захранване |
Input voltage of AC: 100 - 240 V AC, 50/60 Hz; Max. power consumption: 72 W |
| Routing |
Static |
| Памет (Flash, RAM) |
Packet Buffer: 525 KB |
| Капацитет за маршрутизиране/превключване, Gbps |
16 Gbps |
| Пропускателна способност, Mpps |
11.9 Mpps |
| MAC адреси |
8000 MAC address table size |
| VLAN (брой, стандарти) |
802.1Q Static VLANs: 256, Port-based/Voice/MAC-based/Vendor ID based VLAN; VLAN Trunking |
| QoS |
802.1p queuing methods: SPQ, WRR, WFQ and CoS; Storm control: broadcast, multicast, unknown unicast; Port-based rate limiting; 802.3x flow control; DSCP |
| L2 мрежови стандарти |
IEEE 802.3, 802.3u, 802.3ab,802.3x, 802.3az, 802.1p, IEEE 802.3af PoE, IEEE 802.3at PoE+ |
| IPv6 functionality |
IPv6 over Ethernet, IPv6 addressing architecture; Dual stack; ICMPv6; Path MTU; Minimum Path MTU size of 1280; Encapsulation for maximum PMTU size of 1500; Neighbor Discovery |
| Сигурност |
Layer 2 MAC filtering, Static MAC forwarding, SSH v2, SSL, Port isolation/security; MAC freeze; RADIUS; DHCP Snooping; CPU protection; SHA2 HTTPS Certification |
| Размери (Ш, Д, В), mm |
250 x 104 x 27 |
| Опция за монтаж |
Desktop |
