| Суич, тип |
Fixed Port |
| Общ брой портове |
28 |
| Основни портове, тип |
24x 100/1000Base-T |
| Power Over Ethernet (PoE) |
High power PoE 802.3at, 24 PoE ports (up to 375W total) |
| Uplink портове |
4x Combo 1000BaseT/SFP ports |
| Свободни (10GB) слотове |
No |
| Управление |
Cloud management by Nebula Control Center, New for V4.70 Networked AV mode by Web Interface, Zyxel iStackingTM, Web interface, Management through Web interface, Console, Telnet, SNMP, Multilevel CLI, CLI, DHCP |
| Stackable |
No |
| Fans |
- |
| Захранване |
Internal ( 100 to 240 V AC, 50/60 Hz) |
| Routing |
- |
| Памет (Flash, RAM) |
32 MB/256 MB |
| Капацитет за маршрутизиране/превключване, Gbps |
56 Gbps |
| Пропускателна способност, Mpps |
42 Mpps |
| MAC адреси |
16000 MAC address table size |
| VLAN (брой, стандарти) |
802.1Q static VLANs/dynamic VLANs: 1 K/4 K; Port-based/Protocol-based/IP subnet-based/MAC-based/Private/Voice/Vendor ID based VLAN, VLAN ingress filtering, MVR |
| QoS |
8 queues per port, Storm control and event log: Broadcast, multicast, unknown unicast (DLF), Port-based rate limiting (ingress/ egress), Rate limiting per IP/TCP/UDP per port, Policy-based rate limiting , 802.3x flow control, 802.1p Class of Service, DSCP |
| L2 мрежови стандарти |
IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3af PoE, IEEE 802.3at PoE plus, IEEE 802.3az EEE, IEEE 802.3x flow contro, • IEEE 802.1ab LLDP/LLDP-MED, IEEE 802.3ad, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p |
| L3 мрежови стандарти |
- |
| IPv6 functionality |
IPv6 over Ethernet, IPv6 addressing architecture, Dual stack, ICMPv6, Path MTU, Minimum path MTU size of 1280, Encapsulation for maximum PMTU of 1500 , Neighbor discovery, DHCPv6 relay, DHCP client IPv6, DHCP snooping IPv6 |
| Сигурност |
Port security, Layer 2 MAC filtering, Layer 3 IP filtering, Layer 4 TCP/UDP socket filtering, Static MAC forwarding, RADIUS, TACACS+, SSH v2, SSL, DHCP, Policy-based security filtering, Port isolation and etc. |
| Размери (Ш, Д, В), mm |
441 x 270 x 44 |
| Опция за монтаж |
Rackmount |
